¤TV/AV key：

①Satellite TV Finder(DVB-S)

②AV input function.(Monitor)

¤Support DVB-S (MPEG-2)satellite signal video decoding.

¤Support DVB-S2/MPEG-4/CBS-2(HD)/ABS-S signal display test.

¤Find satellite signal alarm and signal enlarge display.

¤Find star signal quality LED displayed,

INFO article shows of signal shape,with enlarge images

¤Warning sound change:the faster pace, signal is stronger

¤Live FTA digital pictures and sounds(DVB-S).

¤ Function:strongest signal locked and auto/blind/TP scan.

¤AV output (video/audio output other TV/Monitor)

¤Bulit-in battery,can find satellite 2.5 hours

¤Remote control function; Comes with horn and compass for debugging use

1.Satellite finder <DVB-S>

¤Frequency range:950MHz-2150MHz

¤LNB power & switch:13V18V/22K / signal lock indicator

¤Input impedance: 75Ώ (F).  LNB short-circuit protection

¤DiSEqC:1.0 & 1.2 edition   Built-in signal locked alarm

¤Built-in satellite finder management

¤Upgrade:edited USB docking RS232

¤Menu language:Chinese/English /French /Arabic/Turkey/Russian

2.AV Input:(on AV state;TV state is AV output)

¤Support Video & Audio &DC12V power test

¤AV Input (Video&Audio Input Monitor)

¤4.3"digital display LCD( LED Back Light)

¤Dots pixels:480*272(391680Pixes)

¤Color system: PALNTSC

¤Lithium battery:DC 7.4V  2600mAh(built-in)

¤Battery indicator light show

¤Input voltage:DC9V  1A

¤output voltage:DC12V
